ورق جاذب امواج ماکروویو LS-30
ورق جاذب LS-30 با ضخامت 0.125 اینچ با ابعاد 29x21 سانتیمتر مناسب برای فرکانس 1 تا 26 گیگاهرتز.
ورق جاذب امواج ماکروویو LS-30
LS-30 .125X24X24 / ECCOSORB / UOM=EA
Applications
-ECCOSORB LS is used to lower cavity Q’s in RF amplifiers, oscillators, cabinets containing microwave devices, computer housings, LNB’s, and isolation of antennas by insertion loss
-ECCOSORB LS is also used to reduce surface currents on radiating elements and outer ground-plane type surfaces.
-Reflectivity of an object (metal or otherwise) can be reduced somewhat by applying one or more layers of ECCOSORB LS to its surface.
Availability
-Standard sheets are 24” x 24” (61 cm x 61 cm)
-Standard thicknesses are 1/8” (0.3cm), 1/4” (0.6cm),
3/8” (0.9cm), 1/2” (1.3cm) & 3/4” (1.8cm)
-Upon special request, ECCOSORB LS can be supplied with an anti-dust coating UMSEAL (UM), to prevent carbon fallout
-ECCOSORB LS can be supplied with a CERSEAL coating to prevent moisture uptake in high humidity to moderately wet environments upon special request
-For applications requiring ECCOSORB LS to be in close contact with electrical components, a PEF film is available on request to prevent electrical shorts
-ECCOSORB LS can also be supplied with a Pressure Sensitive Adhesive (PSA). Product designation denoting ECCOSORB LS with a PSA is ECCOSORB LS-XX/SS3
- ECCOSORB LS is available in other sizes and customer specified configurations upon request
Applications
-ECCOSORB LS is used to lower cavity Q’s in RF amplifiers, oscillators, cabinets containing microwave devices, computer housings, LNB’s, and isolation of antennas by insertion loss
-ECCOSORB LS is also used to reduce surface currents on radiating elements and outer ground-plane type surfaces.
-Reflectivity of an object (metal or otherwise) can be reduced somewhat by applying one or more layers of ECCOSORB LS to its surface.
Availability
-Standard sheets are 24” x 24” (61 cm x 61 cm)
-Standard thicknesses are 1/8” (0.3cm), 1/4” (0.6cm),
3/8” (0.9cm), 1/2” (1.3cm) & 3/4” (1.8cm)
-Upon special request, ECCOSORB LS can be supplied with an anti-dust coating UMSEAL (UM), to prevent carbon fallout
-ECCOSORB LS can be supplied with a CERSEAL coating to prevent moisture uptake in high humidity to moderately wet environments upon special request
-For applications requiring ECCOSORB LS to be in close contact with electrical components, a PEF film is available on request to prevent electrical shorts
-ECCOSORB LS can also be supplied with a Pressure Sensitive Adhesive (PSA). Product designation denoting ECCOSORB LS with a PSA is ECCOSORB LS-XX/SS3
- ECCOSORB LS is available in other sizes and customer specified configurations upon request
کد محصول
EP-MACRO-1
وضعیت موجودی
نا موجود
