مبدل افزاینده DC به DC متغیر 4 آمپر XL6009
DSN6009 is a 4A switching current performance boost module. The module uses a second-generation high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577
مبدل افزاینده DC به DC متغیر 4 آمپر XL6009
DSN6009 is a 4A switching current performance boost module. The module uses a second-generation high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577
DSN6009 boost module
Model Specifications
The modular nature
Rectification: Non-synchronous rectification
Input Range: 3V ~ 32V
Output range:5V ~ 35V
Input Current:
4A (maximum), no-load 18mA ( 5V input, 8V output, no-load is less than 18mA . The higher the voltage, the load current increases.)
Conversion efficiency:
<94% (the greater the pressure, the lower the efficiency)
Switching frequency:
400KHz
Output ripple:
50mV (the higher the voltage, the greater the current, the greater ripple)
Load Regulation:
±0.5%
Voltage Regulation:±0.5%
Operating temperature:-40℃~ +85℃
Dimensions:43mm * 21mm * 14mm (length * width * height)
